PRODUCT DETAILS
The FM-1000/1100 system is an easy set up for flow investigations. Once the camera is focused on particles on the laser light sheet, flow information is captured and analyzed, giving instantaneous velocity field results for that particular plane.
Capturing a sequence of images provides useful statistical information such as average velocities field, vorticities, and shear, as well as time-animations; providing detailed information regarding vortex trajectories and evolving regions of high and low velocity.
Both the FM-1000 and FM-1100 share the same system components: laser, camera, synchronizer and software. The exception is the BG-1000 bubble generator,which is designed for air flow applications. Therefore, the FM-1000 system with the BG-1000 bubble generator included is catered for air flow applications, while the FM-1100 is a system ideal for water flow measurements.
| FM-1000 | FM-1100 |
|---|---|
| Model BG-1000 Micro bubble generator to seed air flows | Model 10089 seed particles |
| Continuous laser with integrated laser light sheet optics | |
| Model 630104-18GB Phantom VEO410 high resolution and high frame rate camera | |
| Model 610036 LaserPulse Synchronizer | |
| Insight 4G software package to control the data acquisition and data processing | |
APPLICATIONS
- Flow distribution and aerosol transport in coughing and sneezing
- Measurements in wind tunnels and water channels
- Turbulent flow investigations
- Are More Pixels Better? Application Note (PIV-023) A4
- Definition of Time-Resolved for PIV Data Application Note (TRPIV-003) A4
- Dynamic Masking for PIV Images App Note (PIV-018) A4
- Flow Characterization of Bio-Medical Devices App Note (PIV-026) A4
- Flow Measurements – Flexible Sphere using Soap Bubbles as Tracer – BG-1000 App Note (PIV-025) A4
- Flow Visualization Systems for Fluid Flow Research Application Note (PIV-019) A4
- Global Liquid Concentration Analyzer Instant Measurements of Global Concen Field App Note (A4)
- Increasing Light Sheet Divergence Angle App Note (PIV-021) A4
- INSIGHT 4G and INSIGHT V3V-4G Syn. Experiments SW Capabilities (INSIGHTV3V-4G-003) A4
- Large-Scale Dual PIV Measurements in Wind Tunnel using Soap Bubble Tracers App Note PIV-029 (A4)
- Pressure Evaluation from Velocity Measurements App Note (PIV-022) A4
- Proper Orthogonal Decomposition (POD) To Extract Flow Information Application Note (A4)
- Simultaneous LDV and PIV Measurements Downstream of a Cylinder (POWERSIGHT-004) A4
- Size Shape Analysis for Measuring Dust Dynamics and Particle Size (SSA-002) A4
- Super Resolution Particle Velocimetry Application Note (A4)
- Time-Resolved Backlit PIV Measurements of a 2-Phase Flow (Bubbles and Media) App Note (TRPIV-005) A4
- Time-Resolved Particle Image Velocimetry (PIV) Post Processing App Note PIV-027 (A4)
- Time-Resolved PIV Measurements of a Horseshoe Vortex App Note (TRPIV-004) A4
- Time-Resolved Stereo-PIV Measurements Downstream Circular Cylinder App Note (SPIV-009) A4
- Uncertainty Analysis for PIV Measurements App Note (PIV-017) A4
